Tours horizontaux (3)

Broche principale : Alésage de la broche (D.I.) : 80 mm Nez de broche : ASA A2-8 Revolver: Tourelle automatique à 4 cavités SQT-190-87-C Doublure (avant) : Mandrin universel à 3 mors ASA8 Diamètre : Ø 315 mm Vitesse : 1250 tr/min Passage intérieur (D.I.) : 103 mm Accessoires : Jeu de 3 mors de base Ø 315 mm Accessoires : Jeu de 3 mâchoires rigides Ø 315 mm Accessoires : Jeu de 3 mâchoires de capote Ø 315 mm Doublure (dos) : Mandrin universel à 3 mors (arrière) Diamètre : Ø 315 Passage intérieur (D.I.) : 103 mm

turning diameter: 270 mmturning length: 630 mmcontrol: SIN840D swing over bed: 400 mmswing diameter over slide rest: 220 mmlongitudinal slide -travel: 745 mmcross slide - travel: 200 mmturning speeds: 10 - 4.000 U/minpower capacity at 100 % load: 15,00 kWspindle head DIN 55026 - Size: 6 spindle bore: 62 mmchucking diameter: max. 315 mmfeed x-axis: 1 - 12.000 mm/minrapid traverse X-axis: 12,00 m/minFeed z- axis: 1 - 20.000 mm / min.rapid traverse Z-axis: 20,00 m/mintailstock quill taper MT: 3 quill stroke: 112 mmquill pressure: 10,00 kNtool turret with 12 work positions: tool taper DIN 69880: Ø 30 mmTool drive speed max.: 4.000 1/mintotal power requirement: 37,00 kWweight of the machine ca.: 4,00 tdimensions of the machine ca.: 4,00 x 2,75 x 2,30 mWith SIEMENS SINUMERIK 840D control system, turret with driven tools, C-Axis, tailstock, chip conveyor, various tool holders.The data for thi ...

turning diameter: 140 mmturning length: 615 mmcontrol: C200-4D spindle passage: 65 mmMain spindle: turning speeds: 5.000 U/minmax. torque at 40% / 100% load: 145 / 105 kWturret-slide: 1,2 und 3 x-travel: 110 mmz-travel: 360 mmy-travel: 70 mmrapid traverse X/Y/Z: 25/12/45 m/minOpposed spindle: slide travel X-axis: 150 mmZ- Travel: 600 mmturning speeds: 5.000 U/minB - axis: B-Korrekturachse +/- 1 °tool turret - number of stations: 3 x 12 tool taper DIN 69880: VDI 25 x 48 C-axis: 0,001 °total power requirement: 61 kWweight of the machine ca.: 6,5 tdimensions of the machine ca.: 9,75 x 3,10 x 2,85 mLoading:Breuning Profimat 65.8x270/8 multi-channel loading magazine, built in 2005for bars with lengths of 500–3,000 mm, 8 guide channels with spindle insert tubes (Ø 16, 25, 30, 40, 45, 55, 60, 65 mm)Unloading:BREUNING ILS-REX-7208 automatic workpiece unloader, built in 2007The data for th ...
