Installations d'usinage par électro-érosion (EDM) AGIE AC Progress VP3
machines de travail des métaux / d'autres machines de travail des métaux / Installations d'usinage par électro-érosion (EDM)
Agie Wire Cutting EDM Machine High-Precision Wire EDM System This 2018 Agie AC Progress VP3 represents top-tier wire electrical discharge machining (EDM), offering flawless contour accuracy and superior surface finishes for critical components. Technical Details 1. Machine identification data ...
Fabricant: AGIE
Modèle:AC Progress VP3
Type de machine: Installations d'usinage par électro-érosion (EDM)
Numéro de l'article: 169370168
Quantité: 1
Date: 21.04.2026
Année de fabrication: 2018
Emplacement:
Allemagne
Velbert
Prix:
Seller-item-No.:527
Agie Wire Cutting EDM Machine
High-Precision Wire EDM System
This 2018 Agie AC Progress VP3 represents top-tier wire electrical discharge machining (EDM), offering flawless contour accuracy and superior surface finishes for critical components.
Technical Details
1. Machine identification data
Name: Wire Cutting EDM Machine (Electric Discharge Machining)
Manufacturer: Agie
Model: AC Progress VP3
Machine number: 591.3.020.530
Year of manufacture: 2018
2. Operational parameters
Travel (X / Y / Z): 500 x 350 x 426 mm
Travel (U / V): ± 70 mm
Max. taper angle: 30° at 100 mm height
Max. workpiece dimensions (X / Y / Z): 1050 x 650 x 420 mm
Max. workpiece weight (without water): 400 kg
Max. workpiece weight (with water): 800 kg
Wire diameters: 0.15 – 0.33 mm
Generator: IPG-VPC
Max. cutting rate: > 500 mm²/min
Best surface roughness: Ra 0.2 µm
3. Weights
Total machine weight: 4200 kg
4. Dimensions
Overall machine dimensions (Width x Length x Height): 2300 x 1940 x 2600 mm
Disclaimer: The technical specifications provided are for general reference only and have been sourced from publicly available information for the same or similar model.
High-Precision Wire EDM System
This 2018 Agie AC Progress VP3 represents top-tier wire electrical discharge machining (EDM), offering flawless contour accuracy and superior surface finishes for critical components.
Technical Details
1. Machine identification data
Name: Wire Cutting EDM Machine (Electric Discharge Machining)
Manufacturer: Agie
Model: AC Progress VP3
Machine number: 591.3.020.530
Year of manufacture: 2018
2. Operational parameters
Travel (X / Y / Z): 500 x 350 x 426 mm
Travel (U / V): ± 70 mm
Max. taper angle: 30° at 100 mm height
Max. workpiece dimensions (X / Y / Z): 1050 x 650 x 420 mm
Max. workpiece weight (without water): 400 kg
Max. workpiece weight (with water): 800 kg
Wire diameters: 0.15 – 0.33 mm
Generator: IPG-VPC
Max. cutting rate: > 500 mm²/min
Best surface roughness: Ra 0.2 µm
3. Weights
Total machine weight: 4200 kg
4. Dimensions
Overall machine dimensions (Width x Length x Height): 2300 x 1940 x 2600 mm
Disclaimer: The technical specifications provided are for general reference only and have been sourced from publicly available information for the same or similar model.
