112 ALZMETALL machine à vendre

bore capacity in steel (diameter): 18.0 mm throat: 190 mm bore stroke: 80 mm morse taper: 2 Kurzspindel MK turning speeds: 225 - 4.300 U/min voltage: 400 / 50 Hz Volt table:: 300 x 240 mm column diameter: 65 mm engine output: 0.37 / 0.55 kW weight: 110 kg Furnishing: - Large spindle speed range - stepless speed adjustment - machined base plate - Electrically secured spindle protection - Main switch lockable with motor protection switch - Reversing switch for clockwise and counterclockwise rotation - Operating instructions in German The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 50.0 mm throat: 300 mm bore stroke: 160 mm threading: M 30 turning speeds: 100 - 1600 U/min table:: 615 x 430 mm bore spindles - Morse Taper: 4 Kurzspindel MK column diameter: 145 mm feed: 0.1-0.2-0.3-0.4 mm/U distance spindle /table: 147 / 688 mm engine output: 1.8 / 2.9 kW weight: 450 kg Machine height: 1865 mm Furnishing : - automatic feed with electromagn. Feed clutch - 4 feed rates 0.1-0.2-0.3-0.4 mm / rev - stepless speed adjustment - digital speed display - Feed overload protection - Spindle protection with electr. validation - digital speed display - machined base plate - Motor 1.8 / 2.9 KW - 100 - 1600 rpm. Special accessories included: - LED machine light pos. 12. - Thread cutting device pos. 20.0 (Thread cutting with stop) - Coolant device A pos. 24. (Coolant base plate, complete) - digital drilling depth display pos. 37.1 (5-digit LED dis ...

bore capacity in steel (diameter): 40.0 mm bore capacity in cast iron: 50.0 mm throat: 300 mm bore stroke: 160 mm morse taper: 4 MK table:: 615 x 430 mm threading: 24 in ST M threading: 30 in GG M turning speeds: 100 - 1.800 U/min feed: 0.1-0.2-0.3-0.4 mm/U distance spindle /table: 147 / 688 mm total power requirement: 0.6 / 1.8 kW weight: 470 kg height of the machine: 1865 m Furnishing: - Electromagnetic feed clutch - with overload protection and electrical cross-handle switch - Lockable main switch - Motor protection switch - Mushroom pushbutton (latching) for EMERGENCY STOP, in the front panel - Infinitely variable speed adjustment - Digital speed display - Protection class IP 54 - Spindle protection with electrical fuse - Motor insulation class F (155 degrees) - Operating instructions in German including special equipment: - LED machine light pos. 12. - Thre ...

capacité d’alésage dans l’acier (diamètre) : mmgorge : 290 mmcourse d’alésage : 180 mmpuissance totale requise : 1,9 kWpoids de la machine env. : tdimensions de la machine env. : mLes données de cette annonce ont été créées avec ModulMWS - la solution logicielle de LogoTech oHG.

bore capacity in steel (diameter): 30.0 mm throat: 293 mm bore stroke: 140 mm morse taper: 3 MK table:: 515 x 360 mm turning speeds: 225 - 4300 U/min engine output: 1.0 / 1.6 kW column diameter: 115 mm distance spindle /table: 132 / 724 mm weight: 260 kg Machine height: 1790 mm Furnishing: - stepless speed adjustment - Reversing switch for R / L run - digital speed display - Connector and cable mounted - Spindle protection with electr. validation - 2 mtr. Connection cable with plug 16A The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 23.0 mm throat: 250 mm bore stroke: 100 mm morse taper: 2 MK table:: 370 x 300 mm turning speeds: 225 - 4300 U/min column diameter: 90.0 mm distance spindle /table: 140 / 670 mm engine output: 0.6 / 0.95 kW weight: 175 kg Machine height: 1770 mm Furnishing : - Mushroom pushbutton (latching) for EMERGENCY STOP - Reversing switch for clockwise and counterclockwise rotation - Motor protection switch - Infinitely variable speed adjustment - Digital speed display - Protection class IP 54 - Connection plug (fully assembled, cable length 2m) - Spindle protection with electrical fuse - Painting: DD textured paint, light gray RAL 7035, anthracite RAL 7016 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 40.0 mm throat: 293 mm bore stroke: 120 mm morse taper: 3 MK table:: 515 x 360 mm turning speeds: 80 - 1125 U/min column diameter: 115 mm thread: M 24 ST60 thread: M 30 GG20 feed: 0.10 + 0.20 mm/U distance spindle /table: 117 / 701 mm engine output: 1.0 / 1.6 kW weight: 270 kg Machine height: 1840 mm NEW ALZMETALL MODEL RANGE 7 TFT - LCD display with touch function: Spindle speed setpoint Actual speed display Integrated drilling depth display with touch zero point transfer Virtual drilling depth scale in the display Machine status displays and warnings in the display Service information Selectable user language: DE / EN / FR / ES / IT / NL / RU. Furnishing: - Thread cutting device for thread cutting with a stop max. 6 threads / min (thread cutting performance depends on the spindle speed) Thread depth adjustable via depth stop in the TFT - ...

bore capacity in steel (diameter): 40.0 mm throat: 293 mm bore stroke: 120 mm morse taper: 3 MK table:: 515 x 360 mm turning speeds: 160 - 2250 U/min column diameter: 115 mm feed: 0.10 + 0.20 mm/U T-slots: 2 x 14 x 224 mm distance spindle /table: 117 / 701 mm engine output: 1.45 / 1.90 kW weight: 285 kg Machine height: 1840 mm NEW ALZMETALL MODEL RANGE 7 TFT - LCD display with touch function: Spindle speed setpoint Actual speed display Integrated drilling depth display with touch zero point transfer Virtual drilling depth scale in the display Machine status displays and warnings in the display Service information Selectable user language: DE / EN / FR / ES / IT / NL / RU. Furnishing: - Infinitely variable speed setting by means of an adjusting lever - automatic spindle feed with feed overload protection - Spindle protection with electrical fuse - Three separate buttons for cloc ...

bore capacity in steel (diameter): 60.0 mm threading: M 42 throat: 350 mm bore stroke: 200 mm turning speeds: 60 - 1530 U/min table:: 720 x 510 mm bore spindles - Morse Taper: 4 Kurzspindel MK column diameter: 200 mm feed: 0.15-0.2-0.3-0.36 mm/U distance spindle /table: 159 / 884 mm engine output: 3.6 / 4.3 kW weight: 605 kg Machine height: 1950 mm Furnishing : - automatic feed with electromagn. Feed clutch - 4 feed levels 0.15 / 02, - 0.3 - 0.36 mm / rev - stepless speed adjustment - digital speed display - Feed overload protection - Spindle protection with electr. validation - digital speed display - machined base plate including special equipment: - Coolant device mounted in the foot pos. 24. - Thread cutting device pos. 20.0 - LED machine light pos. 12. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Offre 25249 Spécifications: - Capacité de perçage en acier ST 60 32 mm - Capacité de perçage en acier ST 60 45 mm - Support de broche de perçage MK 4 - Course de la broche de perçage 160 mm - Projection 300 mm - Table avec 2 rainures en T 500 x 370 mm - Diamètre de la colonne 145 mm - Alimentations - Électromagnétique 0,1 - 0,2 - 0,3 mm/tr - Avec protection contre les surcharges - Vitesses de la broche de perçage réglables en continu - Niveau 1 : 65 - 240 + 240 - 875 tr/min - Niveau 2 : 130 - 480 + 480 - 1750 tr/min - Entraînement 400 V / 1,4 / 2,2 kW - Encombrement approximatif L 650 x H 1900 x P 800 mm - Poids env. 450 kg

Capacité de perçage 32 mm Montage sur broche MK 3 Projection 290 mm Course du pinol 160 mm Dimensions de la table 510 x 300 mm Diamètre de la colonne 115 mm Vitesse de la broche 55 - 1450 tr/min réglable en continu Puissance du moteur 0,9 et 1,3 kW commutables en pôles Raccordement au réseau 380 volts, 50 Hz. Vitesse de la broche via 2 étages d’engrenage, 2 vitesses du moteur et variable en continu via un engrenage de variateur Réglage de la hauteur de la table à l’aide d’une manivelle Lumière de la machine Mandrin sans clé 1 à 13 mm Espace requis L x l x H 1200 x 650 x 1900 mm Poids 400 kg

bore capacity in steel (diameter): 55.0 mm threading: M 30 / M 42 throat: 300 mm bore stroke: 140 mm turning speeds: 70 - 1200 U/min table:: 615 x 430 mm bore spindles - Morse Taper: 4 Kurzspindel MK column diameter: 145 mm feed: 0.10 + 0.30 mm/U distance spindle /table: 150 / 735 mm weight: 380 kg Machine height: 1850 mm Furnishing : - automatic feed - Feed device 0.1 + 0.3 mm / rev - stepless speed adjustment - digital speed display - Feed overload protection - Spindle protection with electr. validation including special equipment: - Coolant device mounted in the foot pos. 24. - Thread cutting device pos. 20.0 (Thread cutting with stop) - LED machine light pos. 12. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 30.0 mm throat: 293 mm bore stroke: 140 mm morse taper: 3 MK table:: 515 x 360 mm turning speeds: 225 - 4300 U/min column diameter: 115 mm distance spindle /table: 132 / 724 mm engine output: 1.0 / 1.6 kW weight: 260 kg Machine height: 1790 mm NEW ALZMETALL MODEL RANGE 7 TFT - LCD display with touch function: Spindle speed setpoint Actual speed display Integrated drilling depth display with touch zero point transfer Virtual drilling depth scale in the display Machine status displays and warnings in the display Service information Selectable user language: DE / EN / FR / ES / IT / NL / RU. Furnishing: - Infinitely variable speed setting by means of an adjusting lever - Spindle protection with electrical fuse - Three separate buttons for clockwise rotation - counterclockwise rotation - stop - Mushroom pushbutton (latching) for EMERGENCY STOP -  ...

capacité d’alésage en acier (diamètre) : mmgorge : 290 mmcourse d’alésage : 160 mmpuissance totale requise : 1,9 kWpoids de la machine env. : tdimensions de la machine env. : mDescription à suivre ! Les données de cette annonce ont été créées avec ModulMWS - la solution logicielle de LogoTech oHG.

capacité d’alésage en acier (diamètre) : 32 mmgorge : 290 mm course d’alésage : 180 mmpuissance totale requise : 1,9 kWpoids de la machine env. : tdimensions de la machine env. : mDescription à suivre ! Les données de cette annonce ont été créées avec ModulMWS - la solution logicielle de LogoTech oHG.

capacité d’alésage dans l’acier (diamètre) : mmgorge : 290 mmcourse d’alésage : 180 mmpuissance totale requise : 1,9 kWpoids de la machine env. : tdimensions de la machine env. : mLes données de cette annonce ont été créées avec ModulMWS - la solution logicielle de LogoTech oHG.

Offre 25234 Spécifications: - Capacité de perçage en acier ST 60 32 mm - Capacité de perçage dans l’acier ST 60 40 mm - Axe long MK 3 - Vitesses de la broche de perçage réglables en continu - Niveau 1 : 160 - 1125 tr/min - Niveau 2 320 - 2250 tr/min - Course de la broche de perçage 120 mm - Avances 0,1 + 0,2 mm/tr - Projection 293 mm - Diamètre de la colonne 115 mm - Taille de la table 300 x 300 mm - Avec 2 rainures en T 14 x 224 mm - Bouton d’arrêt d’urgence - Étau de machine - 10 pièces HSS – forets 10 – 25 mm - Encombrement approximatif L 500 x H 1750 x P 900 mm - Poids env. 270 kg

capacité d’alésage dans l’acier (diamètre) : 40 mmgorge : 325 mm course d’alésage : 170 mm surface de table : 730 x 590 mm0 : 130 - 1200 U/avance minimale : 0,09 - 0,16 - 0,28 mm/cône Utool : MK 4 puissance totale requise : 1,8 kWpoids de la machine env. : 0,7 tdimensions : 1,2 x 0,8 x 2,15 mPerceuse avec :Avance2 vitessesRotation gauche/droitePédale de commandeÉclairage de la machineLes données de cette annonce ont été créées avec ModulMWS - la solution logicielle de LogoTech oHG.

Offre 25170 Spécifications: - Capacité de perçage dans l’acier ST 60 40 mm - Capacité de perçage en acier ST 60 50 mm - Support de broche de perçage MK 4 - Course de la broche de perçage 180 mm - Vitesses de la broche de perçage réglables en continu avec arbre intermédiaire - Niveau 1 : 60 - 210 tr/min - Niveau 2 210 - 765 tr/min - Niveau 3 120 - 420 tr/min - Niveau 4 : 420 - 1530 tr/min - Projection 330 mm - 3 alimentations 0,1 - 0,2 - 0,3 tr/min - Table avec 2 rainures en T 720 x 360 mm - Réglable en hauteur via un porte-bagages à l’aide d’une manivelle - Table de distance max. – broche de perçage env. 780 millimètre - Distance max. de la plaque de base usinée - broche de perçage 1250 mm - Dispositif de refroidissement -Éclairage - Étau de machine - div. 10 pièces HSS - Perceuse - Entraînement 400 V /  ...

bore capacity in steel (diameter): 45 mm throat: 350 mm bore stroke: 180 mm : 4 speeds: 30 - 765 U/min table-size: 720 x 560 mm total power requirement: 3,4 kW weight: 950 kg dimensions: 1200 x 800 x 2300 mm Column drilling machine OPTIdrill DP 33V promotion set / 3020680SET With an electronically controllable drive in a modern design Industrial engine Quiet running spindle thanks to new spindle design Machine operation with safety electronics in 24 V direct current Guaranteed concentricity = 0.02 mm in the measured drilling spindle Clockwise/counterclockwise rotation Precision spindle bore Control panel with user-friendly, dirt and water resistant Membrane keyboard RPM display Separate emergency stop button Tapping function Precisely crafted, stable drill table with diagonal T-slots with all-round cooling water channel, can be tilted sideways by ±45° and rotated by 360°  ...

: ja alimentation : 80 - 800 m/min  : 1848 poids de la machine env. : 2,2 t

Poids : 1,4 t

Capacité de perçage : 35 mm, montage : MK4, vitesse : 1400 tr/min, avance : 0,4 mm/tr. Une inspection sur place est possible.

bore capacity in steel (diameter): 60 mm throat: 400 mm bore stroke: mm total power requirement: 4,4 kW weight of the machine ca.: 1,7 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: 40 mm : M 24 : M 30 spindle turning speed - stepless: 160-2.250 U/min : MK 3 spindle stroke: 120 mm throat: 293 mm column diameter: 115 mm : 515x360 mm distance spindle /table: min./max. 117/701 mm : 2 x 14 x 224 mm feed: 0,1 + 0,2 mm/U Machine height: 1840 mm weight: 270 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 40 mm throat: 300 mm bore stroke: 180 mm turning speeds: 55-1450 U/min Feed: 0,1-0,3 mm/U keyless drill chuck: machine.: Nummer 5112 table surface area: 620x470 mm spindle taper metric: 4 thread cutting attachment: The tech. Data are manufacturer or operator information and therefore non-binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solution of LogoT ...

bore capacity in steel (diameter): 40 mm throat: mm bore stroke: mm total power requirement: 4 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore diameter: 65 mm throat: 380 mm Control: PLC-Steuerung bore spindle turning speed range: 63 - 1600 U/min table-size: 630 x 500 mm rapid traverse Z-axis: 4,75 m/min boring feeds:: 0,05 - 0,56 mm/U total power requirement: 9 kW weight of the machine ca.: 2,0 t dimensions of the machine ca.: 1,50 x 1,20 x 2,95 m Drilling capacity in steel ST60: 65 mm Drilling capacity in cast iron GG20: 80 mm Thread cutting ST60: M68 Thread cutting GG M72 SPS-controlled automatic drilling machine with Drilling/deep hole drilling/thread cutting Sequence: 1st rapid traverse to start position 2. switch on the speed 3. switch on the drilling feed 4. drilling until the drilling depth is reached 5. return in rapid traverse to start position Manual operation possible (speed and direction of rotation, rapid traverse positioning, Switching the drill feed on/off) Selection of the drill feeds and spindle speed man ...

bore capacity in steel (diameter): 50 mm throat: 385 mm bore stroke: 240 mm table surface area: ø 500 mm spindle taper MT: 5 spindle turning speed range: 40 - 800 U/min feeds: 0,1/0,14/0,2/0,28/0,4 mm/U column diameter: 220 mm distance between table/spindle: max. 670 mm distance spindle/base plate: 1180 mm total power requirement: 4 kW weight of the machine ca.: 1,4 t dimensions of machine L x W x H: 1,5 x 0,75 x 2,4 m Accessories: drill chuck, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 50 mm, 800 1/min

Vitesses réglables en continu de 40 à 800 tr/min 4 Avances de forage . Clairement en bon état d’origine
