WITTMANN BATTENFELD EcoPower 110/130 UNILOG B6 All Electric Machines de moulage par injection

Ref. no.: 18625
Manufacturer: WITTMANN BATTENFELD
Year of construction: 2011
Clamping unit
Clamping force: 110 ton
Opening stroke: 380 mm
Distance between tie bars: 470 x 420 mm
Mould height min.: 200 mm
Mould height max.: 450 mm
Platen size (h x v): 680 x 663 mm
Injection unit
Screw diameter: 30 mm
Injection volume: 88 cm³
Shot weight: 80 g
Injection pressure: 1471 bar
Measurements and weight
Dimensions: 4,8 x 1,4 x 2,2 m
Machine weight: 4600 kg
Further information:
Wittmann Battenfeld EcoPower series represents high-efficiency all-electric injection moulding technology designed for precision production and stable processing performance.
All major machine movements are driven by servo electric motors. Injection, dosing, clamping and ejector movements are performed completely electrically, ensuring extremely precise motion control, excellent repeatability and stable production quality.
Compared to conventional hydraulic injection moulding machines, the EcoPower series can achieve approximately 60% up to 80% energy savings depending on the application. In addition, the machines offer lower heat generation, quiet operation and a cleaner production environment.
The integrated UNILOG B6 / B6P control system is well known for its user-friendly operation, reliable process management and stable long-term performance. Combined with high dynamic servo technology and low-vibration operation, the EcoPower platform is especially suitable for technical plastic parts, electronic components, automotive applications and medical production.
Today, the Wittmann Battenfeld EcoPower series is still considered one of the most reliable and energy-efficient all-electric injection moulding machine platforms on the market.
