45 SCHLEICHER machine à vendre

SCHLEICHER WV-PL 160/800 coil feeding line was built in 1987 in Germany by H. Schleicher GmbH & Co. Maschinenfabrik. The line is used for the automatic feeding of material from a coil to presses and other machines used in metal forming. The automation of this process stage improves mass production, increases its efficiency and reduces the need for manual work. The SCHLEICHER WV-PL 160/800 coil feed line consists of a roller feeder, a straightening machine and a sheet metal decoiler. It is designed for coils with a maximum width of 800 mm and a weight of 200 kg. A 4 mm thick material strip is decoiled and straightened, then fed directly into the machine’s working area. The precisely adjustable feed rate ensures uniform strip feeding, which translates into process repeatability and stable operation of the entire line. All this makes the SCHLEICHER press feed line an excellent choice f ...

Pression maximale: 9 tonnes Force de pressage : 1,94 kg/cm² Taille de la balle: 770x600x500 mm Poids de la balle: - Alimentation : 400 V/4 kW Année de construction : 1997 Productivité: - Prix: sur demande

Key data: 450 , 1 , 1400

Charge utile 1200 kg Largeur 450 mm Diamètre extérieur de la bobine - jusqu’à 1400 mm Moteur 1,5 kW Vitesse réglable par conversion de fréquence Btto 500 kg

Key data: 300 , 4

Bande passante - jusqu’à 460 mm Épaisseur du ruban adhésif - 0.5 - 4 mm Moteur - 6 kW ensemble avec Bobine 1.5 T - sans lecteur

material width:850 mm material thickness:0,3 - 1,5 mm no. of straightening rolls:8 straightening roll diameter:40 mm number of draw-in rolls:2 diameter of draw-in rolls:160 mm material thickness with 600 mm material width:1,9 mm material thickness with 400 mm material width:2,3 mm speed:5 - 25 m/min min. material width:200 mm weight:2,8 t Dimensions (WxDxH):1,6 x 2,2 x 2,3 m

material width:850 mm material thickness:0,3 - 1,5 mm no. of straightening rolls:8 straightening roll diameter:40 mm number of draw-in rolls:2 diameter of draw-in rolls:160 mm material thickness with 600 mm material width:1,9 mm material thickness with 400 mm material width:2,3 mm speed:5 - 25 m/min min. material width:200 mm weight:3,1 t Dimensions (WxDxH):2,2 x 1,5 x 2,8 m

material width:200 mm material thickness:0,8 - 3,0 mm no. of straightening rolls:6 straightening roll diameter:53 mm number of draw-in rolls:2 diameter of draw-in rolls:96 mm material cross-cut:400 mm² speed:3 - 15 m/min power capacity:0,75 kW weight:0,5 t Dimensions (WxDxH):1,0 x 1,0 x 1,4 m

material width:450 mm material thickness:0,5 - 1,0 mm no. of straightening rolls:6 straightening roll diameter:53 mm number of draw-in rolls:2 diameter of draw-in rolls:96 mm power requirement:1,0 kW weight:0,65 t dimensions (WxDxH):1,0 x 1,0 x 1,55 m

material width:200 mm material thickness:0,5 - 3,0 mm no. of straightening rolls:6 straightening roll diameter:70 mm number of draw-in rolls:2 diameter of draw-in rolls:160 mm power requirement:3,1 kW weight:1,1 t dimensions (WxDxH):1,5 x 1,2 x 1,9 m

material width:800 mm coil weight:12,0 t coil internal diameter:470 - 520 mm coil external diameter:1500 mm material thickness:0,4 - 2,5 mm no. of straightening rolls:8 straightening roll diameter:53 mm number of draw-in rolls:2 inlet roll diameter:160 mm speed:35 m/min material thickness at 150 mm material width:2,5 mm material thickness at 650 mm material width:1,5 mm material thickness at 800 mm material width:1,0 mm straightening machine:RM 8-53/160-800 decoiler:HE 200-1000

material width:450 mm material thickness:1,0 - 14,0 mm coil weight:10,0 t coil internal diameter:470 - 520 mm coil external diameter:1100 - 2000 mm no. of straightening rolls:12 straightening roll diameter:2x70 / 2x96 / 8x127 mm number of draw-in rolls:2 inlet roll diameter:160 mm min. material width:100 mm speed:15 m/min power requirement:75,0 kW weight of decoiler:6,4 t weight of straightening machine:12,8 t dimensions decoiler (WxDxH):3,1 x 1,4 x 3,7 mm dimensions straightener (WxDxH):2,5 x 3,4 x 2,7 mm straightening machine:RMS-Vario-12-70/96/127-0450 infinitely variable drive:insert drive upper straightening part:hydraulic liftable loop bridge:hydraulic driven threading wedge:hydraulic decoiler:HES 12-650 infinitely variable drive:insert drive lag brake:pneumatic snubber roll:hydraulic; motoric driven expansion:hydraulic coil lifting device:hydraulic cropping shears:HS-150-0450

band width: 850 mm total power requirement: 3,8 kW 5 to. Schleicher reel - max load: 5 to - Belt width: 1500 mm - Belt thickness: 1 mm - Year of construction: 23/04/92 - Voltage: 24/380 V 50 Hz - Power: 3,8 KW Including: Coil lifter, feed unit, control panel, hydraulic unit, control cabinet The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Poids de la bobine : 1 tonne Largeur du matériau : 150 mm Diamètre extérieur de la bobine : 1200 mm Plage d’expansion : 480 - 520 mm Épaisseur : 0,5 - 4 mm

Manufacturer: Schleicher Promodul UNG 230 mit 11 Stück Access Modulen 1 Rack Access und XCX 700, Sale without warranty: 11 Stück Access Modulen , No right of return: 1 Rack Access , Installation height: XCX 700,

Manufacturer: Schleicher RACK Access UKE, Type: UKE, Model: Input Rack,

Machine à onglets Schleicher F7 N° série 48111- Inspection vidéo en ligne par Skype-Vidéo Nous serions très heureux de votre visite - plus de machines en stock disponibles immédiatement - Peut être inspecté En stock Emskirchen / Nürnberg - Peut être testé

CONTROLS   conventional DECOILER   sheet width max.: 1050 mm   coil weight max.: 5 to LEVELLER UNIT   sheet width max.: 1000 mm   sheet thickness max.: 5 mm   sheet thickness min.: 0.4 mm STRIP-FEEDER   feeder type: roll feeder SCHLEICHER H-5 coil unwinder, max. load 5 t, power 3.92 kW, strip width 1,050 mm, with lifting table; SCHLEICHER RM8-70 EW 160 straightening machine, year of manufacture 1979, 38,712 operating hours, power 7.62 kW, strip width 1,000 mm, strip thickness 0.4 - 5 mm, 4 straightening rollers each on top and bottom, SCHLEICHER feeder

Ordinateur de contrôle pour presses Desma

Cam switches, circuit breakers, tap switches, rotary switches, cam switching devices, miniature micro pushbuttons -Manufacturer: Schleicher, cam switches -Type: PK 15 -Voltage: 220V 50Hz -Dimensions: 235/110/H110 mm -Weight 1.1 kg

Time relay, relay, heating current monitoring, contactor, semiconductor contactor, contactor -Type: KZT01 -5-100 s Price: per piece -Quantity: 5 available -Weight: 0.2 kg

Position processor, SLAVE CPU POSITIONING -Manufacturer: SCHLEICHER, 2-axis positioning assembly -Type: USP21 -No.: 31506913-310 -Number: 2 modules available -Price: per piece -Dimensions: 150/35/H200 mm -Weight: 0.6 kg/pc.
