28 ZAYER machine à vendre

Ce centre d’usinage vertical Zayer 30KF 3000 à 3 axes a été fabriqué en 1997. Il offre une construction robuste et une précision pour des tâches d’usinage complexes. Idéal pour ceux qui recherchent des performances fiables dans une machine d’occasion. Contactez-nous pour plus d’informations.

Key data: 6000 mm, 2000 mm, 3000 mm

Type de machine : Fraiseuse à colonne mobile CNC Marque ZAYER Type KCU6000 Année de construction 1992 Type de commande Heidenhain TNC 415 Voie X (mm) 6 000 Y-off (mm) 2 000 Z-off (mm) 3 000 Vitesses de (tr/min) 20 à 1 800 Porte-outil BT50 Avance longitudinale (mm/tr) 5 - 5000 mm/min Avance transversale (mm/U) 5- 5000 mm/min. Vitesse d’avance verticale (mm/tr) 5- 5000 mm/min. Déplacement rapide 10 000 mm/min. Puissance totale (KW) 34 Longueur (mm) 11 000 Largeur (mm) 2 500 Hauteur (mm) 7 000 Poids 31.000 kg Information Table rotative 'Juaristi MG6' : 1500 x 1200 mm Avec pompe à liquide de refroidissement Système de refroidissement : 2,5 bar Refroidissement de l’outil : 15 bar

x-travel: 6000 mm y-travel: 2000 mm z-travel: 3000 mm Control: heidenhain TNC 415 total power requirement: 34 kW weight of the machine ca.: 31 t dimensions of the machine ca.: 7000 mm m Stocknumber 1110055 Type of machine CNC Floortype milling machine Make ZAYER Type KCU6000 Build in 1992 Type of control Heidenhain TNC 415 X-stroke (mm) 6.000 Y-stroke (mm) 2.000 Z-stroke (mm) 3.000 Speeds (Rpm) 20 - 1.800 Admission in spindlehead BT50 Feeds X (mm/R) 5 - 5000 mm/min Feeds Y (mm/R) 5- 5000 mm/min. Feeds Z (mm/R) 5- 5000 mm/min. Rapid feeds 10.000 mm/min. Total Power (KW) 34 Lenght (mm) 11.000 Width (mm) 2.500 Height (mm) 7.000 Weight 31.000 Kg Additional information Juaristi MG6 turntable: 1500 x 1200 mm Cooling system: 2.5 Bar Tool cooling: 15 Bar The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 4700 mm y-travel: 1000 mm z-travel: 1000 mm control: HEIDENHAIN TNC355 table-size: 5000x1000 mm T-slots: 7x mm turning speed range: 2800 U/min feed: 6-5000 mm/min rapid traverse: 15000 mm/min spindle motor: 30,00 kW spindle taper: SK 50 Table load: 10.000 kg Main drive: 40 PS weight of the machine ca.: 27,00 t dimensions of the machine ca.: m With HEIDENHAIN TNC 355 control. Machine can be inspected under power. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Code 8529 Description Fraiseuse à lit CNC Faire Zayer Type 2200 BF 3 Machine nmb 52248 Année 1986 Contrôle Fagor 8020 Taille de la table 2200 x 800 mm Table de mouvement (X) 1830 mm Bélier transversal (Y) 1016 mm Tête de fraisage à traverse verticale (Z) 1016 mm Cône de broche ISO 50 Poids maximum sur la table 4000 kg Lol de vitesses de broche 18 étapes Vitesses de broche 28 - 1800 tr / min Flux dir. Progr. X-Y-Z 3 – 5000 mm/min Rapides Longitudinal 5 m/min Croix 5 m/min Vertical 5 m/min Poids total 10.000 kg Mainmotor 11 kW Connexion d’alimentation 38 KVA Tension 380 Volt Accessoires Tête de fraisage Horiz./Vert. avec ISO-50 Hydr. dispositif de serrage d’outil Condition La machine est en bon état

Fraiseuse à portique ZAYER KFU 3000

x-travel: 8000 mm y-travel: 2500 mm z-travel: 1000 mm control: Heidenhain TNC 355 taper ISO: 50 spindle speeds: 20 - 1800 mm voltage: 380 V total power requirement: 27,6 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 4.700 mm y-travel: 1.250 mm z-travel: 1.500 mm control: HEIDENHAIN iTNC 530 clamping table: - surface area: 5.000 x 1.000 mm max. workpiece weight: 10.000 kg T-slot number x size: 7 x 22 Abstand 140 mm Universal Milling Head: _ Swiveling area front/back level: automatisch Indexing: 0,001 x 0,001° stepless Constant Power at 100 % ED: 37 kW Speed range, stepless: 35 - 4.500 min-1 max. torque: 880 Nm tool taper: SK 50 – DIN 69871 internal coolant system feed: durch das Spindelzentrum automatic tool changer ATC: - Tool places: 60 Plätze diameter of tools max.: 125/240 mm workpiece length: 300 mm weight of tools max.: 25 kg feeds: - X-, Y- and Z-axis, stepless: 6 - 15.000 mm/min rapid in X/Y/Z: 25.000 m/min max. feed force X-Y-Z-axis: 10.000 N total power requirement: kW weight of the machine ca.: 35 t dimensions of the machine ca.: 12,7 x 5,6 x 4,2 m Equipment / Accessories:Hea ...

x-travel: 10000 mm y-travel: 1500 mm z-travel: 3000 mm Control: Heidenhain TNC 430 tool taper: ISO 50 spindle turning speed - stepless: 10 - 3000 U/min feed range: 10000 mm/min rapid traverse: 15 m/min main drive motor: 37 kW total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m CNC-control HEIDENHAIN TNC 430 40-station ATC NC-Universal Milling head, automatic positioning (A/B axis 0.001 / 0.001 deg) Chip conveyor Optional (price upon request): CNC rotary table Juaristi 3000 x 3000 mm - Table load 30 to - Longitudinal movement 2000mm - Separate CNC-control FAGOR The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 7000 mm y-travel: 2000 mm z-travel: 1250 mm control: Heidenhain iTNC 530 plate size: 7000 x 1500 mm tool change unit: 60 Pos turning speeds: 35 - 4500 U/min spindle motor: 37 kW rapid traverse: 20 / 10 m/min total power requirement: - kW weight of the machine ca.: - t required space: - m equipped with: - Heidenhain iTNC 530 CNC control - Tool changer for 60 tools (ISO 50) - autom. Milling head (0,001 °) - Spindle cooling 15bar with paper band filter - Chip conveyor - Renishaw RMP 60 - Extra Miling Head (Spare Part) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 10000 mm y-travel: 3000 mm z-travel: 1500 mm Control: Heidenhain TNC 430CA milling head -swivable: 360.000 pos spindle turning speed range: 10 - 3000 U/min Tools changer: 40 pos. feed: 5000 mm/min Rapid Travel X / Y / Z-Achse: 10 / 15 / 15 m/min spindle motor: 37 kW total power requirement: 80 kVA weight of the machine ca.: 40 t dimensions of the machine ca.: m Traveling column milling and boring machine - Control Heidenhain TNC 430CA & HR 410 - autom. Tool changer with 40 places (SK 50) - Huron Universal milling head, automatic Positioning (A-/B-Axis each 0,001°) - Chip conveyor - OPTIONAL: Rotary Table 3000x3000mm - 30t (W-Axes: 2000mm), with independent FAGOR CNC Control The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 5005 mm, 3586 mm, 1106 mm

Année de production : 2007 Changement automatique d’outil Espaces de travail [mm] : 5000x2500 Distance de rainure [mm] : 200 Plages de course [mm] : 5005x3586x1106 Alimentation de travail [m/min] : 35m/min Alimentation rapide [m/min] : 40 Vitesse de broche [tr/min] : 35 - 6000 Couple de la broche [kW] : 37 kW couple maximal [Nm/tr/tr/m] : 670/525 Serrage d’outils : HSK-A 100 Magazine d’outils [pcs.] : 100 000 Système de contrôle de la machine : iTNC 530 2x univerzální úhlová hlava 45 Tête de sortie directe Alimentation électrique

N° Inv. : 7770 Type : KFU 3000 Producteur : Zayer Création : 1990 Paramètres: Système d’exploitation : HEIDENHAIN TNC 415 B Longueur de la table : 3000 mm Largeur de la table : 1000 mm Charge maximale de la table : 10000 kg Max. Vitesse : 3000 1/min Axe X : 2700 mm Axe Y : 1000 mm Axe Z : 1000 mm Dimensions de la machine : 4000 x 2500 x 2800 mm Poids : 18600 kg Équipement: Agrafes (env. 40 pièces) Étaux (2 pièces) Angle (2 pièces) Blocs de serrage (2 pièces)

Zayer 30KCU700AR (2003) avec Heidenhain iTNC 530. - x, y, z = 7000, 2000, 1250 - CTS 15 bar - Tête de fraisage contrôlée (précision de position 0,001) - 60 outils - Moteur de broche de 37 kW - Déplacement rapide 20/10 m/min - 4500 tr/min - ISO50 - Renishaw RPM60 -Convoyeur - Tête de fraisage supplémentaire (remplacement)

x-travel: 10000 mm y-travel: 1500 mm z-travel: 3000 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m - CNC control Heidenhain TNC 415B - controlled 2-axes NC-milling head 2,5° - coolant device The machine will be sold without the plate field Accessories: ca. 20 pieces tool tapers DIN 2080 with bolts DIN 69872 some spare parts like bevel gears for the milling head and ball screw for X-axis. Technische Daten / technical details: Verfahrweg X längs / X-travel longitudinal 10000 mm Verfahrweg Y quer / Y-travel cross 1500 mm Verfahrweg Z vertikal / Z-travel vertical 3000 mm Werkzeugschaft / spindle taper SK50 Drehzahlbereich (2-stufig) / spindle speed (2-steps) 35-3000 UpM /rpm Vorschub / infeed 6-10000 mm/min Eilgang X,Y,Z / rapid feed X,Y,Z 10, 15, 10 m/min Antriebsleistung Hauptmotor 100%ED / drive capacity main motor 100%ED 37  ...

Zayer 30KCU/AR 2003

x-travel: 10000 mm y-travel: 1500 mm z-travel: 2700 mm total power requirement: kW weight of the machine ca.: t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 7.000 mm y-travel: 2.000 mm z-travel: 1.250 mm Control: Heidenhain iTNC 530 Internal cooling system: 15 bar milling head: Automatisch 0,001 spindle turning speed range: 4.500 U/min spindle drive: 37 kW taper ISO: 50 tool change unit: 60 Chip coveyor: Inkl. rapid traverse: 20/10 m/min total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m -CTS 15 bars -Controlled milling head (pos. Accuracy 0,001) -60 tools -37 kw spindle motor -rapid 20/10 m min -4500 rpm -iso50 -Renishaw RPM60 -chip conveyor -extra milling head (spare) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 1700 mm y-travel: 800 mm z-travel: 890 mm table surface area: 2000 x 630 mm spindle taper: SK 50 spindle turning speed range: 35 - 3000 U/min spindle drive: 26 kW feeds longditudinal/cross/vertical: 6 - 5000 mm/min rapid traverse: 15 m/min table load: max. 6000 kg control: HEIDENHAIN control: TNC 360 total power requirement: 45 kVA weight of the machine ca.: 13 t dimensions of machine L x W x H: 5,2 x 2,78 x 2,95 m Accessories: vertical head swivelling in 2 planes with hydr. tool clamping, various tool fixtures, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 12000 mm y-travel: 2500 mm z-travel: 1000 mm control: Heidenhain TNC 415 taper ISO: 50 P.D.B. spindle speeds: 20 - 1800 mm voltage: 380 V total power requirement: 37 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 4700 mm y-travel: 1000 mm z-travel: 1000 mm control: HEIDENHAIN TNC355 table-size: 5000x1000 mm T-slots: 7x mm turning speed range: 2800 U/min feed: 6-5000 mm/min rapid traverse: 15000 mm/min spindle motor: 30,00 kW spindle taper: SK 50 Table load: 10.000 kg Main drive: 40 PS weight of the machine ca.: 27,00 t dimensions of the machine ca.: m With HEIDENHAIN TNC 355 control. Machine can be inspected under power. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 10000 mm y-travel: 1100 mm z-travel: 1700 mm Control: Heidenhain type: TNC 155 Tool changer: 30 table surface area: 10000x1000 mm chip conveyor: universal head: table height over floor: 800 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 3.400 mm y-travel: 1.250 mm z-travel: 2.000 mm Control: TNC-430PA table-size: 4.700 X 1.200 mm V- travel: 500 tool taper: ISO 50 milling head -swivable: 0.001º/0.001º Grad main drive: 37 kW Chip coveyor: inkl handwheel: HR-410 Tools changer: 60 pos. milling head: Automatic Head 45º weight of the machine ca.: 35 t - Automatic Head 45º INCLUDED - Automatic Head 45º 0.001º/0.001º - Head 45º Max. Speed 3.000 rpm - 45º Head Taper ISO-50 - Twist Head Contiuous INCLUDED - Twist Head Max Speed 3.000 rpm - Twist Head Taper ISO-50 - Ram with Quill - Quill Diameter 150 mm. - Quill Taper ISO-50 - Pick up station AITEK for 45º and Twist Heads - Rotary Table ZEATZ Ø 1200 INCLUDED - RENISHAW MP 16+SP2/1 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 22.000 mm y-travel: 1.500 mm z-travel: 3.000 mm Control: SIEMENS 840 D milling head -swivable: 0,001/0,001 Grad milling head: Universalfräskopf 45° Internal cooling system: 20 bar Chip coveyor: ja Tools changer: 30 pos. coolant: 1.100 l Tool taper: DIN 69871A ISO 50 total power requirement: 45 kW weight of the machine ca.: 68 t The round table shown in the pictures as well as the plate field are not sold with ! urning Speeds 6.000 r.p.m. AutoIndex Head 45 º Head 360.000 Pos. Elbow 360.000 Pos. Main Motor Power 37 Kw. Nº Change Range 2 Ranges Automatic Tool Charger INCLUDED Tools at ATC 30 Coolant Through Tool 20 Bar INCLUDED Soluble Oil Tank with filter paper INCLUDED Head Coolant System + CF Box INCLUDED Longitudinal Chip Conveyor INCLUDED Operator?s Platformd with 2000 mm Vertical movement. INCLUDED Ready for Rotor Translating Table (Regulator + Wires) /IN ...

Fabricant ZAYER Modèle 30 KMU-5000 Année 1999 CNC HEIDENHAIN TNC-430PA Surface de table 4 700 x 1 200 mm. Courses (X/Y/Z) 3 400/1 250/2 000 mm. Sortie de l’arbre (axe ouest) 500 mm. Cône de tête ISO-50 Puissance du moteur principal 37 kW Culasse automatique de 45º INCLUSE Rotation de la tête 45º Rotation automatique 0,001º/0,001º Rotations de culasse 45º 3 000 tr/min Cône de culasse ISO-50 à 45º Tête à torsion continue INCLUSE Tête de rotation à 3 000 tr/min Cône à tête tournante ISO-50 Bélier avec canne INCLUS Diamètre de la tige 150 mm. Cône de tige ISO-50 Tête de refroidissement interne et externe de 45º et tige INCLUSE Tête torsadée de refroidissement externe INCLUSE Micro semi-automatique INCLUS Outils de chargement automatique INCLUS Positions des chargeurs Htas 60 Station de récupération AITEK pour un stockage de 45º de culas ...

Cette Zayer KF 4000 à 3 axes a été fabriquée en 1989. Il dispose d’une grande table de 4 000 Ã 1 000 mm, capable de supporter des charges allant jusqu’à 10 000 kg. Équipé d’une vitesse de broche allant jusqu’à 3 000 tr/min et d’une plage de puissance de 30 à 37 kW, il garantit des capacités d’usinage robustes. Envisagez l’opportunité d’acheter ce centre d’usinage universel Zayer KF 4000. Contactez-nous pour plus d’informations sur cette machine.

Machine fixe de fraisage de lit Zayer 2000BF. Tableau: 2500x700mm. Voyage longitudinal: 2000mm. Voyage en croix: 1000mm. Voyage vertical: 1000mm. ISO50. Vitesses: 18. (28-1800rpm). Puissance: 15cv. Poids: 13000Kgs. Équipé de DRO Fagor.

Machine à moudre universelle avec le bélier de mouvement automatique. Tableau: 1700x700. Voyage longitudinal: 1320mm. Voyage en croix: 1016mm. Voyage vertical: 560mm. ISO50. 18 vitesses (28-1800rpm) 18,75 Hp. Poids: 6200Kg.
