aléseuses et centres d'usinage machines d'occasion à vendre (3,255)

CONTROLS  CNC controls HEIDENHAIN ITNC 530 WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 5   X-axis travel: 600 mm  Y-axis travel: 450 mm  Z-axis travel: 450 mm  rotating range B-axis from: -115 °  rotating range B-axis up to: 30 °  rotating range C-axis from: 0 °  rotating range C-axis up to: 360 °TABLE  clamping surface diameter: 450 mm  workpiece load (max): 200 kgSPINDLE / HEAD  spindle revolutions (max): 20000 /minAXIS DRIVES  rapid traverse X: 22000 mm/minTOOL MAGAZINE  number of positions: 220 ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 4400 mm  space requirements -front/back-: 3400 mm  total height: 2700 mm  total weight approx.: 8000 kgATTACHMENTS  digital display: yes   chip conveyor: yes   coolant unit: yes   band filtra ...

The REIDEN RX14 Machining Center, constructed in 2014 and installed in 2015, offers advanced manufacturing capabilities with the HEIDENHAIN TNC640 CNC controller. It features extensive axis travel (X: 1,800 mm, Y: 1,800 mm, Z: 1,210 mm, A: -15° to +105°) and a rapid traverse of 40 m/min. The spindle delivers 15,000 rpm with a power of 63/73 kW for efficient processing. The worktable, measuring ø1,400 x 1,200 mm, supports up to 5,000 kg. Equipped with a 92-slot HSK-A100 tool magazine, it includes numerous enhancements like an electronic handwheel, chip conveyor, and collision monitoring. A precise, reliable machine for demanding applications.

CONTROLS  CNC controls HEIDENHAIN ITNC 620 WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 3   .. among of them simultaneous CNC axes: 3   X-axis travel: 1000 mm  Y-axis travel: 550 mm  Z-axis travel: 550 mmTABLE  table surface (left-right): 1100 mm  table surface (front-back): 550 mm  workpiece load (max): 800 kgSPINDLE / HEAD  spindle type: vertical   spindle revolutions (max): 10000 /min  tool fixture: ISO SK 40   drive power: 13.5 kWAXIS DRIVES  feed velocity (max): 10000 mm/min  rapid traverse X: 36000 mm/min  rapid traverse Y: 36000 mm/min  rapid traverse Z: 36000 mm/minTOOL MAGAZINE  magazin type: disc magazine   number of positions: 30   tool diameter max.: 76 mm  tool length max.: 250 mm  tool weight max.: 6 kgELECTRICAL SPECIFICATIONS  mains power supply: 15 kVADIMENSIONS / WEIGHTS  space requirements -left/ ...

CONTROLS  CNC controls SIEMENS 840 D SL WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 4   X-axis travel: 210 mm  Y-axis travel: 270 mm  Z-axis travel: 360 mmSPINDLE / HEAD  spindle revolutions (max): 40000 /min  tool fixture: HSK A40 TOOL MAGAZINE  number of positions: 64 AUTOMATIC WORKLOAD EQUIPMENT  workpiece manipulator: articulated robot   number of store positions: 32 ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  total weight approx.: 9000 kgATTACHMENTS  chip conveyor: yes   coolant unit: yes   band filtration unit: yes   closed cabin: yes Operating hours: Spindle 1: 4050 h, Spindle 2: 11,114 hInternal cooling 70 barFanuc Automation Robot M-10IAIntegrated workpiece changing deviceKnoll coolant tank Knol KF 400/900

CONTROLS  CNC controls SIEMENS 840D SL 4.8 WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 4   X-axis travel: 210 mm  Y-axis travel: 270 mm  Z-axis travel: 360 mmSPINDLE / HEAD  spindle revolutions (max): 40000 /min  tool fixture: HSK A40 TOOL MAGAZINE  number of positions: 72 AUTOMATIC WORKLOAD EQUIPMENT  workpiece manipulator: articulated robot   number of store positions: 36 ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 8500 mm  space requirements -front/back-: 2500 mm  total weight approx.: 6000 kgATTACHMENTS  central lubrication system: yes   chip conveyor: yes   coolant unit: yes   through spindle coolant attachment: yes   European CE standards: yes -Siemens tool management with retooling-Fanuc Automation Robot M-10IA-Operating hours: 7,200  ...

CONTROLS  CNC controls ROEDERS WORKING RANGE -CUBIC-  .. among of them simultaneous CNC axes: 3   X-axis travel: 500 mm  Y-axis travel: 450 mm  Z-axis travel: 300 mmSPINDLE / HEAD  spindle revolutions (max): 42000 /min  tool fixture: HSK A40 TOOL MAGAZINE  number of positions: 40

CONTROLS  CNC controls SIEMENS 840 D WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 4   .. among of them simultaneous CNC axes: 3   X-axis travel: 2200 mm  Y-axis travel: 1600 mm  Z-axis travel: 1850 mm  rotating range B-axis from: 0 °  rotating range B-axis up to: 360 °TABLE  table surface (left-right): 1000 mm  table surface (front-back): 1250 mm  workpiece load (max): 5000 kgSPINDLE / HEAD  spindle revolutions (min): 20 /min  spindle revolutions (max): 10000 /minAXIS DRIVES  rapid traverse: 40000 mm/minTOOL MAGAZINE  number of positions: 60   tool diameter max.: 110 mm  - with free neighbour positions: 250 mm  tool length max.: 450 mm  tool weight max.: 35 kgAUTOMATIC WORKLOAD EQUIPMENT  number of store positions: 2 ELECTRICAL SPECIFICATIONS  mains power supply: 130 kVA  mains voltage: 400 V  mains frequency: 50 H ...

CONTROLS  CNC controls HEIDENHAIN MILL PLUS WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 5   X-axis travel: 500 mm  Y-axis travel: 420 mm  Z-axis travel: 380 mmSPINDLE / HEAD  spindle revolutions (max): 18000 /min  tool fixture: HSK A63 AXIS DRIVES  feed velocity (max): 20000 mm/min  rapid traverse: 50000 mm/minTOOL MAGAZINE  number of positions: 60 ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 2500 mm  space requirements -front/back-: 2600 mm  total height: 2440 mm  total weight approx.: 6000 kgATTACHMENTS  zero-point workholding system: yes   chip conveyor: yes   coolant unit: yes   band filtration unit: yes   through spindle coolant attachment: yes   closed cabin: yes   European CE standards: yes Total spindle hours: 38800 hours.machin ...

CONTROLS  CNC controls WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 3   X-axis travel: 1040 mm  Y-axis travel: 510 mm  Z-axis travel: 640 mmTABLE  table surface (left-right): 1460 mmSPINDLE / HEAD  spindle revolutions (max): 7000 /minTOOL MAGAZINE  number of positions: 24 ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 Hz

CONTROLS  CNC controls HEIDENHAIN ITNC 530 WORKING RANGE -CUBIC-  X-axis travel: 750 mm  Y-axis travel: 500 mm  Z-axis travel: 600 mmTABLE  table surface (left-right): 1000 mmSPINDLE / HEAD  spindle revolutions (max): 10000 /min  tool fixture: ISO SK 40 ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 6000 mm  space requirements -front/back-: 4500 mm  total height: 2800 mm  total weight approx.: 8000 kgPendulum machining unit2 x 750 mmMachine in very good and well-maintained conditionOnly used for machining aluminum or plasticFeatures:- Various tool holders- 3R clamping system on each side (see photo)- Work area light

CONTROLS  CNC controls SIEMENS SOLUTION LINE WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 3   X-axis travel: 600 mm  Y-axis travel: 560 mm  Z-axis travel: 510 mmTABLE  table surface (left-right): 900 mm  table surface (front-back): 560 mm  workpiece load (max): 600 kgSPINDLE / HEAD  spindle revolutions (min): 20 /min  spindle revolutions (max): 12000 /min  tool fixture: ISO SK 40   drive power S6 40%: 13 kW  drive power S1 100%: 9 kW  spindle torque S6 40%: 82 Nm  spindle torque S1 100%: 54 NmAXIS DRIVES  traverse velocity X (max): 20000 mm/min  traverse velocity Y (max): 20000 mm/min  traverse velocity Z (max): 20000 mm/min  rapid traverse X: 30000 mm/min  rapid traverse Y: 30000 mm/min  rapid traverse Z: 30000 mm/minTOOL MAGAZINE  number of positions: 30   tool diameter max.: 80 mm  - with free neighbour position ...

CONTROLS  CNC controls HEIDENHAIN I TNC 530 WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 4   X-axis travel: 540 mm  Y-axis travel: 540 mm  Z-axis travel: 560 mmTABLE  table surface (left-right): 700 mm  table surface (front-back): 520 mmSPINDLE / HEAD  spindle revolutions (max): 8000 /min  tool fixture: ISO SK 40 AXIS DRIVES  feed velocity (max): 20000 mm/min  rapid traverse: 30000 mm/minTOOL MAGAZINE  number of positions: 21   tool diameter max.: 80 mm  - with free neighbour positions: 160 mm  tool length max.: 385 mm  tool weight max.: 6.8 kgELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 3000 mm  space requirements -front/back-: 2600 mm  total height: 2700 mm  total weight approx.: 4200 kgExtras:- 4th axis- Chip conveyor- Internal coolant  ...

CONTROLS  CNC controls. 3D MILLPLUS IT V600 WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 3   X-axis travel: 500 mm  Y-axis travel: 450 mm  Z-axis travel: 400 mmTABLE  table surface (left-right): 700 mm  table surface (front-back): 500 mm  workpiece load (max): 500 kgSPINDLE / HEAD  spindle revolutions (min): 20 /min  spindle revolutions (max): 10000 /min  tool fixture: ISO SK 40   drive power: 13 kWAXIS DRIVES  traverse velocity X (max): 24000 mm/min  traverse velocity Y (max): 24000 mm/min  traverse velocity Z (max): 24000 mm/minTOOL MAGAZINE  number of positions: 30   tool diameter max.: 80 mm  - with free neighbour positions: 130 mm  tool length max.: 300 mm  tool weight max.: 6 kg  tool changing time: 8 sATTACHMENTS  European CE standards: yes No cooling system; the machine is connected to a central cooling system. ...

CONTROLS  CNC controls MORI SEIKI MSG-501 WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 4   X-axis travel: 1300 mm  Y-axis travel: 1200 mm  Z-axis travel: 1100 mmTABLE  table surface (left-right): 800 mm  table surface (front-back): 800 mm  workpiece load (max): 2000 kgSPINDLE / HEAD  spindle revolutions (max): 0 /min  spindle revolutions (max): 6000 /min  tool fixture: ISO BT 50 AXIS DRIVES  rapid traverse: 42000 mm/minTOOL MAGAZINE  number of positions: 60 ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 7400 mm  space requirements -front/back-: 4300 mm  total height: 3750 mm  total weight approx.: 23500 kgATTACHMENTS  chip conveyor: yes   coolant unit: yes   band filtration unit: yes   through spindle coolant attachment: yes   closed cab ...

CONTROLS  CNC controls FANUC 18 MB WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 4   .. among of them simultaneous CNC axes: 3   X-axis travel: 900 mm  Y-axis travel: 800 mm  Z-axis travel: 980 mm  rotating range B-axis from: 0 °  rotating range B-axis up to: 360 °TABLE  table surface (left-right): 630 mm  table surface (front-back): 630 mm  workpiece load (max): 1200 kgSPINDLE / HEAD  spindle type: horizontal   spindle revolutions (max): 10000 /minAXIS DRIVES  rapid traverse: 50000 mm/minTOOL MAGAZINE  number of positions: 140 AUTOMATIC WORKLOAD EQUIPMENT  store type: table changer   number of store positions: 2 ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  total weight approx.: 19000 kgATTACHMENTS  chip conveyor: yes   coolant unit: yes   band filtration unit: yes   ...

CONTROLS  CNC controls FANUC 310 IS WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 5   X-axis travel: 600 mm  Y-axis travel: 410 mm  Z-axis travel: 460 mm  rotating range A-axis from: -30 °  rotating range A-axis up to: 120 °TABLE  clamping surface diameter: 350 mmSPINDLE / HEAD  spindle revolutions (max): 12000 /min  drive power: 18 kWAXIS DRIVES  rapid traverse: 4800 mm/minTOOL MAGAZINE  number of positions: 30 DIMENSIONS / WEIGHTS  space requirements -left/right-: 3000 mm  space requirements -front/back-: 2400 mm  total height: 1980 mm  total weight approx.: 7500 kgOperating hours: 35`000hInklusieve: Vices see picture

CONTROLS  CNC controls SIEMENS 840 D WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 4   X-axis travel: 550 mm  Y-axis travel: 320 mm  Z-axis travel: 360 mmTABLE  table surface (left-right): 820 mm  workpiece load (max): 500 kgSPINDLE / HEAD  spindle revolutions (max): 24000 /min  tool fixture: HSK A50 AXIS DRIVES  rapid traverse: 75000 mm/minTOOL MAGAZINE  number of positions: 24 AUTOMATIC WORKLOAD EQUIPMENT  workpiece manipulator: articulated robot   store type: table changer   number of store positions: 2 ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  total weight approx.: 7700 kgATTACHMENTS  guideway covers: yes   central lubrication system: yes   chip conveyor: yes   coolant unit: yes   closed cabin: yes   European CE standards: yes - Shuttle table machine- Knoll (KSS)  ...

Porte-pensule pour collets ER25

WORKING RANGE -CUBIC-  X-axis travel: 1270 mm  Y-axis travel: 660 mm  Z-axis travel: 635 mmSPINDLE / HEAD  spindle revolutions (max): 7500 /minBASIC FUNCTIONS  number of spindles: 1   number of turrets: 0   live positions: yes   number of c-axes: 0   number of y-axes: 1   number of b-axes: 0 ATTACHMENTS  chip conveyor: yes WORKING RANGE TURNING  swing diameter (max): 635 mm  worpiece length max.: 1372 mm  workpiece weight max.: 1814 kgMAIN SPINDLE  spindle revolutions (min): 0.001 /min  spindle revolutions (max): 7500 /minX/Z SLIDE  Z-axis travel: 635 mm  X-axis travel: 1270 mm  Y-axis travel: 660 mmTOOL MAGAZINE  tool diameter max.: 178 mm  tool length max.: 406 mm  tool weight max.: 13.6 kg

CONTROLS  CNC controls HEIDENHAIN TNC 426 WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 3   X-axis travel: 500 mm  Y-axis travel: 350 mm  Z-axis travel: 610 mmTABLE  table surface (left-right): 920 mm  table surface (front-back): 380 mmSPINDLE / HEAD  spindle revolutions (min): 50 /min  spindle revolutions (max): 18000 /min  tool fixture: ISO SK 30 TOOL MAGAZINE  number of positions: 24 ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 2000 mm  space requirements -front/back-: 1700 mm  total height: 3000 mm  total weight approx.: 3200 kgATTACHMENTS  chip conveyor: no   coolant unit: yes   through spindle coolant attachment: no   closed cabin: yes   European CE standards: yes Machine in TOP condition- Power ON :    about 37000 h- Spindle hour ...

Contrôle : Fabrication : FANUC 0i-MD x-travel : 1000 mmy-travel : 550 mmz-travel : 500 mmsurface de table : 1100 x 500 mmvitesse de tournage de la broche - en continu : 10000 U/mindimensions de la machine env. : 3500 x 2200 x 2700 mmxmmxmmpoids de la machine env. : 6.5 ttool piece magazine avec : 24 Plätzen Les données de cette annonce ont été créées avec ModulMWS - la solution logicielle de LogoTech oHG.

Course X : 6000 mmVitesse Y : 1000 mmDéplacement Z : 1200 mmTaille de la table : 6400x1000 mmUnité de changement d’outil : 80x cône de broche : HSK A100 Plage de vitesse de rotation de la broche : 45-9000 U/minPuissance totale requise : kWPoids de la machine env. : 48 tDimensions de la machine env. : 12x4.3x4.5 mSIEMENS 840D4ème axe Axe B +/-90Refroidissement de la broche par la brocheAppareil de mesure de l’outil

Contrôle : Fabrication : HEIDENHAIN iTNC 530 x-Travel : 800 mmY-Travel : 500 mmZ-Travel : 540 mmTaille de la table : 910x500 mmPlage de vitesse de rotation de la broche : 10000 U/minMagasin d’outils :: 24 Poids de la machine env. : 8 tHEIDENHAIN TNC-426Préparé pour le 4ème axe

Control: HEIDENHAIN TNC-430 x-travel: 800 mmy-travel: 600 mmz-travel: 500 mmB-axis (table): 280 mmtable swivelabel +/-: 220 (+/-110) °-C-axis table rotating: 360 °tool magazin:: 30 spindle taper: HSK63 spindle turning speed - stepless: -15000 U/minrapid traverse feeds rotary table: 36 U/minrapid travel x/y/z: 36 m/minOverall size: 3800X3600X3000 mmweight of the machine ca.: 8.5 tCoolant through spindle: pressure: 40 Bar3D measuring tracer: RENISHAW Chip conveyor: Coolant installation: SIEMENS 840Dwww.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Capacité d’alésage dans l’acier (diamètre) : 25 mmGorge : 245 mmCourse d’alésage : 120 mmPoids de la machine env. : 1,35 tDimensions de la machine env. : 1,6 x 1,5 x 2,4 m

Contrôle : Fabrication : SIEMENS 840D x-travel : 600 mmy-travel : 560 mmz-travel : 510 mmtaille de la table : 900 x 560 mmplage de vitesse de rotation de la broche : 12000 U/minmagasin d’outils :: 30 poids de la machine env. : 5 tHEIDENHAIN TNC-426Préparé pour le 4ème axe

Course x : 762 mmCourse y : 508 mmCourse z : 508 mmAxe B (table) : +120/-35 Axe C Grad: 360 Gradcontrol : HAAS für 5 Magasin d’outils Achsenavec : 40 PlätzenNombre de vitesses de broche : 12000 U/minDimensions de la machine env. : 4,3 x 2,35 x 2,8 mPoids de la machine env. : 8,5 t

Contrôle : Fabrication : FANUC 0iM x-course : 620 mmVitesse y : 470 mmDéplacement z : 400 mmTaille de la table : 700 x 450 mmPlage de vitesse de rotation de la broche : 10000 U/minMagasin d’outils :: 20 Poids de la machine env. : 4.5 tHEIDENHAIN TNC-426Préparé pour le 4ème axe

Diamètre de carottage max. : 16 mm Profondeur de l’alésage : 485 mmDiamètre de l’oscillation : x mmTaille de la table : 590x350 mmPlage de vitesse de rotation de la broche : 230-2300 U/minPoids de la machine env. : 0,4 tTable avec lecturenumérique Accessoires divers

capacité d’alésage dans l’acier (diamètre) : 18 mmGorge : 225 mmCourse d’alésage : 110 mmTaille de la table : 430x345 mmVitesse de rotation de la broche - en continu : 135-4500 U/minAffichagenumérique Accessoirede taraudage Table transversale 530x255mmAccessoires divers
